- Description
- Specification
2.Quiet operation
3.Universal style mounting bracket fits existing mounting holes
4.Double break contacts ensure positive make and break
5.Screw terminals or pressure connectors and double 1/4 quick connects provided on all models for easy installation
|
Insulating material |
Contact block and carrier are high quality electrical-grade thermosetting resin |
|
Temperature range |
-40°F to 150°F |
|
Mechanical life (no load) |
Conforms to UL and ARI specifications |
|
Electricl life |
Conforms to UL and ARI specifications |
|
Weight (approximate) |
9.25 oz |
|
Coils Frequency |
50/60Hz |
|
Coil insulation |
Class B (130℃) |
|
Termination |
Pressure connector and double 1/4 Q.C |
|
Operate |
85%of nominal coil coltage;110% maximum safe operate |
|
Duty cycle |
Continuous |
|
Model No |
Full load |
Resistive Amps(A) |
Pole No. |
Coil Voltage ( V) |
Line Voltage (V) |
Max HP |
|
|
|
Amps( A ) |
50/60HZ |
Voltage (V) |
Single Phase |
Three Phase |
||||
|
CJX9-20/1 |
20 |
30 |
1 |
24 |
240/277 |
120 |
1.5 |
- |
|
CJX9-20/1.5 |
1.5 |
|||||||
|
CJX9-20/2 |
2 |
|||||||
|
CJX9-20/3 |
3 |
120 |
480 |
240/270 |
3 |
7.5 |
||
|
CJX9-20/4 |
4 |
208/240 |
600 |
480/600 |
- |
7.5 |
||
|
CJX9-25/1.5 |
25 |
35 |
1.5 |
24 |
240/277 |
120 |
2 |
- |
|
CJX9-25/2 |
2 |
|||||||
|
CJX9-25/3 |
3 |
120 |
480 |
240/270 |
5 |
7.5 |
||
|
CJX9-25/4 |
4 |
208/240 |
600 |
480/600 |
- |
15/20 |
||
|
CJX9-30/1.5 |
30 |
40 |
1.5 |
24 |
240/277 |
120 |
2 |
- |
|
CJX9-30/2 |
2 |
120 |
480 |
240/270 |
5 |
10 |
||
|
CJX9-30/3 |
3 |
208/240 |
600 |
480/600 |
- |
15/20 |
||
|
CJX9-30/4 |
4 |
|||||||
|
CJX9-40/2 |
40 |
50 |
2 |
24 |
240/277 |
120 |
3 |
- |
|
CJX9-40/3 |
40 |
50 |
3 |
120 |
480 |
240/270 |
7.5 |
10 |
|
CJX9-40/4 |
40 |
50 |
4 |
208/240 |
600 |
480/600 |
- |
15/20 |
|
CJX9-50/2 |
50 |
60 |
2 |
24 |
240/277 |
120 |
3 |
|
|
CJX9-50/3 |
50 |
60 |
3 |
120 |
480 |
240/270 |
10 |
15 |
|
CJX9-50/4 |
50 |
60 |
4 |
208/240 |
600 |
480/600 |
- |
25/25 |
|
CJX9-60/2 |
60 |
70 |
2 |
24 |
240/277 |
120 |
5 |
- |
|
CJX9-60/3 |
60 |
740 |
3 |
120 |
480 |
240/270 |
10 |
20 |
|
CJX9-60/4 |
60 |
70 |
4 |
208/240 |
600 |
480/600 |
- |
30/30 |
|
CJX9-75/2 |
75 |
85 |
2 |
24 |
240/277 |
120 |
5 |
- |
|
CJX9-75/3 |
75 |
85 |
3 |
120 |
480 |
240/270 |
15 |
25 |
|
CJX9-75/4 |
75 |
85 |
4 |
208/240 |
600 |
480/600 |
- |
40/40 |
|
CJX9-90/2 |
90 |
100 |
2 |
24 |
240/277 |
120 |
7.5 |
- |
|
CJX9-90/3 |
90 |
100 |
3 |
120 |
480 |
240/270 |
20 |
30 |
|
CJX9-90/4 |
90 |
100 |
4 |
208/240 |
600 |
480/600 |
- |
50/50 |
